Turin · Heat Exchanger · Rotary Pump Turin Gallatin R HX Espresso Machine with Rotary Pump & PID & Flow Control

365 Day Home Trial Only at Cliff & Pebble

★★★★★

Turin

Turin Gallatin R HX Espresso Machine with Rotary Pump & PID & Flow Control

Name: Turin Gallatin R HX Espresso Machine with Rotary Pump & PID & Flow Control
Brand: Turin
SKU: sku-41724380381259
Price: 1599.0 USD
Availability: OutOfStock
Rating: 5.0 (1 reviews)

Rotary pump heat exchanger with built-in flow control. The Gallatin for serious home baristas.

$1,599.00

Free shipping · No sales tax on most orders · 365-day returns · 1-year warranty

Select Option

🛡️

365-Day ReturnsLongest return window in the industry

🚚

Free ShippingFully insured, ships in 1–2 business days

🏷️

Price MatchFound it cheaper? We'll match it

🔧

1-Year WarrantyManufacturer coverage included

The Turin Gallatin R HX is the top of the Gallatin lineup — everything the V HX has, plus a commercial-grade rotary pump and built-in flow control. The rotary pump runs nearly silent, supports direct plumb without a hand valve, and delivers more consistent pressure than a vibratory pump. Flow control is standard: the paddle lets you shape pressure through pre-infusion and extraction, opening up shot profiling that most machines at this price can't touch. If you want the full Gallatin experience without compromise, this is the one.

2L Heat Exchanger

Single boiler maintained at steam temperature with an HX circuit for brew water. Brew and steam simultaneously.

PID Temperature Control

Independent PID on both boilers. Dial in brew temperature to the degree — essential for light roasts.

E61 Group Head

Thermosyphon preheating. Commercial 58mm portafilter. The standard for espresso precision since 1961.

Adjustable Pre-Infusion

Programmable pre-infusion and integrated shot timer for consistent, repeatable extractions.

Rotary Pump

Near-silent commercial-grade pump. More consistent pressure, longer service life, full direct-plumb support.

Eco Mode

Reduces energy consumption when idle without compromising performance when you're ready to pull.

Is the Gallatin R HX right for you?

You want to brew and steam simultaneously without the cost of a dual boiler.

You make milk drinks daily and want zero workflow compromise.

You're upgrading from a single boiler or entry-level machine and want to feel the difference immediately.

You want a near-silent machine — the rotary pump is a significant upgrade over vibratory for quiet kitchens and early mornings.

You want flow control built in — the R HX includes it standard with no add-on needed.

What's Included

Turin Gallatin Dual Boiler Espresso Machine
58mm double-spouted portafilter
Single and double filter baskets
Walnut-handle tamper
Fast-connector for direct plumb
Cleaning disc + backflush powder
User manual + warranty card
Complimentary shipping (fully insured)
365-Day In-Home Trial
1-Year Warranty

Specifications

Boiler Type	Heat exchanger — 2 liter
Group Head	E61 thermosyphon
Pump	Rotary vane — near-silent, direct plumb capable
Temperature Control	PID — independent on both boilers
Pre-Infusion	Adjustable
Shot Timer	Yes — integrated
Flow Control	Built-in — included standard
Water Supply	Reservoir or direct plumb (manual valve)
Portafilter	58mm commercial
Height	15.55″
Width	11.26″
Depth	17.44″
Weight	53.5 lbs
Origin	Designed by Turin (Michigan, USA)

"The full Gallatin experience. Rotary pump, flow control standard, direct plumb capable. This is the one you don't outgrow."

— Cliff & Pebble Team

Common Questions

Everything you want to know

Both are heat exchanger machines that let you brew and steam simultaneously. The Mara X V2 has Lelit's brew mode which eliminates the HX cooling flush — a meaningful workflow advantage. The Gallatin V HX is significantly less expensive and includes optional flow control as an add-on. If budget is the primary constraint, the Gallatin V HX is a strong value. If you want the best HX experience and the flush-free workflow, the Mara X V2 is worth the extra investment. Call 800-410-8867 and we'll help you choose.

Yes — flow control is built into the Gallatin R HX as a standard feature. The paddle gives you manual control of water pressure through pre-infusion and extraction. Combined with the rotary pump's stable, consistent pressure, this is a genuinely capable shot profiling setup.

The Gallatin DB uses a standard 58mm portafilter. We recommend the Turin DF64 Gen 2.7 or the Turin CF64V as strong pairings at this machine's level. Call 800-410-8867 for a personalized recommendation based on your workflow.

Yes — the Gallatin R HX includes a fast-connector for direct plumb. You can run it on the internal reservoir or connect it directly to a water line using the manual valve.

365 days — the longest return window in the espresso industry. If the Gallatin DB isn't right for you within a full year, we'll take it back or help you upgrade.

Video library

Unboxing the Gallatin R HX

How it compares

Which Gallatin is right for me?

	You're viewing Turin Gallatin R HX	Turin Gallatin V HX	Turin Gallatin Dual Boiler
Price	$1,499.00	$1,249.00	$1,949.00
Boiler	Heat Exchanger	Heat exchanger	Dual boiler
Flow control	Yes — paddle	Optional	Yes — paddle
Brew + steam at once	Yes	Yes	Yes
Direct plumb	Yes	No	Yes
Pump	Rotary	Vibration	Rotary
Best for	Rotary pump, flow control, direct plumb — the full package. ☕	The most capable heat exchanger in its price class.	Dual boiler performance at a heat exchanger price.
	View Turin Gallatin R HX	View Turin Gallatin V HX	View Turin Gallatin Dual Boiler
